| Throat diameter: | 1" (25.4 mm) |
| Nominal impendance: | 8 Ohm |
| Power capacity (AES): | 25 W |
| Peak Power: | 200 W |
| Sensitivity | |
| CD Horn 90° x 75° 1 W / 1 m: | 113 dB |
| Plane Wave Tube, 1 W / 1 m: | 117dB |
| Maximal SPL (cont.): | 127 dB at 25 W |
| Frequency Range: | 1200 - 30000 Hz |
| Recommended Crossover: | 1900 Hz |
| Magnet Material: | Ferrite |
| Flux Density (Tesla): | 1.8 |
| Voice Coil Material: | Copper Clad Aluminum |
| Voice Coil Former: | Kapton TM |
| Diaphragm Material: | Polyester |
